Digital and Analog CBR Test Apparatus, Civil Engineer Bangladesh

Original price was: 90,000.00৳ .Current price is: 75,000.00৳ .

Analogue CBR tester

  • Brand : Customized
  • Model : Customized
    Manufacturing Country : Customized
  • Country of Origin :Customized
  • Analogue CBR tester BD,

CALIFORNIA BEARING RATIO APPARATUS MOTORISED

Category:

Description

Bangladesh Civil engineering Company generally use The California Bearing Ratio test (usually called CBR test) is an empirical test developed in California, USA. It determines the relative bearing ratio and expansion characteristics under known surcharge weight of base, subbase and subs soils for the design of roads, pavements and runways. The CBR test is used extensively in selection of materials and control of sub grades.



The test can be performed in the laboratory on prepared samples or in-situ on location. Because of the empirical nature of the test, it is valid only for the application for which it was developed: the design of highway base thicknesses.



This load frame is designed for conducting unconfined, triaxial, CBR and other routine tests.



The loading system comprises of a screw jack with detachable handle. The lower platen moves up and down. The top bracket is adjustable for vertical clearance and has an adaptor for connecting standard proving rings. A dial gage mounting bracket is provided on one of the two pillars. Rate of strain: 1.00 and 1.27mm/min.
